CCTV Camera Pros Geovision 8.5 Multicam Digital Surveillance System - Manual (Page 614)

596
11.13 Spot Monitor Controller
GV-Combo Card (GV-1008 / 1120 / 1280 / 1480) and GV-Combo A Card (GV-1120A / 1280A / 1480
A) come equipped with a TV output allowing you to connect one spot monitor or TV monitor to the
computer. With the Spot Monitor Controller, you can define the screen divisions, set the channel
sequence of each scanned page and adjust video images on the additional monitor.
11.13.1 Spot Monitor Controller
To start the Spot Monitor Controller, follow these steps:
1. Click the Configure button (No. 14, Figure 1-2), select Accessories, select DSP Spot Monitor,
and select Spot Monitor Setup. This dialog box appears.
Figure 11-77
2. Select Use DSP as Spot Monitor at next Startup, and click OK.
3. Restart the GV-System.
4. Click the Configure button (No. 14, Figure 1-2), select Accessories, select DSP Spot Monitor,
and select Spot Monitor Controller. The Spot Monitor Controller window appears.
Note: When the DSP Spot Monitor Control feature is enabled, DSP Overlay will be disabled in the
Main System.
