Video
Analysis
145
3
4.
In the Definition section, there are three options:
Mask Region: Use the mouse to outline a mask area where motion will be ignored.
Min Object Size: First click the
button to pause live images and then use the mouse
to outline the minimum object size for tracking on the image.
Max Number of Tracked Objects: Use the slider to choose the maximum number of
objects to be tracked. The maximum value is 7. This number also determines how many
navigation boxes would be left free for selecting focus areas of interest in PAP View. See
Object Tracking in PAP View later in this chapter.
Dwell Time of Motion: After a targeted object stops moving, the image will remain
magnified for the number of seconds specified.
5.
In the Option section, selecting Smart Zoom In can focus the upper part of the targeted object
during tracking.
6.
To activate the function at certain times only, click the Schedule button and select Active
Schedule. For details, see Video Analysis Schedule later in this chapter.
7. Click
OK to apply the settings.
Note:
1. The function will stop tracking an object when it remains stationary in the camera view for 3
seconds.
2. It takes about 3 to 5 seconds to start tracking after you switch to another channel for object
tracking.
