84
1.11 PTZ Control
With the PTZ control panel, you can control PTZ functions, e.g. pan, tilt, zoom, focus and preset points.
This control panel will not appear, unless at least one PTZ camera is connected to the system.
For analog cameras, you must first complete the steps below to enable PTZ control.
1. Click Configure button (No. 14, Figure 1-2), select Accessories, select PTZ Device and select
Add / Remove PTZ. This dialog box appears.
Figure 1-68
2. Select the brand of your camera, and click the button.
3. Click OK and then restart the GV-System.
4. Click Configure button (No. 14, Figure 1-2), select Accessories, select PTZ Device and select
PTZ Device Setup. This dialog box appears.
Figure 1-69
5. Select the brand of your camera and click the button. A dialog box appears.
6. Select Active. This is important! Without this step the PTZ camera will not be added to the
system.
7. Click OK.
