138
3.1.2 Object Zooming
If only one PTZ camera is available, without the stationary camera, you can simply apply it for the
object zooming function. The feature allows you to configure up to 4 critical views for instant
monitoring and zooming.
Setting up a PTZ Camera
Before configuring the Object Zooming function, first configure the PTZ device. Refer to Setting up a
PTZ Camera in Object Tracking earlier in this chapter.
Setting up Object Zooming
After the above PTZ setup, go back to the menu bar.
1. Click the Configure button (No. 14, Figure 1-2), point to Video Analysis, select Object Tracking
Application, and select Object Tracking Setup to display the Object Tracking Config dialog box.
Then click the Zoom in Object tab in the upper part to display the following dialog box.
Note: The image on the right will not display until you complete the settings below.
Figure 3-8
