302
6.3.5 Overlaying Input Name onto Screen upon Input Trigger
This feature is designed to overlay the name of input device on live video for alert or save it to video
files whenever the input is triggered.
Figure 6-12
Select an Input number to be set up. Clicking the Finger button can apply the same settings to all
inputs. The input name can be found and modified in Figure 6-1.
[I/O Overlay] Click Setup to display this dialog box, use the drop-down lists to select the input module
and pin number, and then select camera(s) associated with the input device..
Figure 6-13
To overlay the name of triggered input on live video, click the Configure button (No. 14 , Figure 1-2),
select General Setting, select Text Overlay Setting, and select Print on screen (Only for I/O alarm)
or Print on video file. You can also select the position of the name stamp on the screen. For details,
see POS Data Overlay in Chapter 7.
Note: Up to 5 input names can be stamped on each channel when inputs are triggered.
