150
„ Define Object Size: Select this option and click the button to pause live images. Use
the mouse to outline a region matching the normal size of the targeted object.
3. To test your counting settings, select Live from the Test Count drop-down list and click the Test
button to start testing. Notice how the number changes in the Counting Result section when
objects cross the boundary lines. Use the Sensitivity slider to increase or decrease detection
sensitivity if the passing objects are not counted correctly.
4. To activate the function at certain times only, click the Schedule button and select Active
Schedule. For details, see Video Analysis Schedule later in this chapter.
5. Click OK to apply the settings.
6. Start monitoring to begin counting.
