168
3.9 Unattended and Missing Object Detection
The Object Monitor program can detect any unattended and/or missing object within the camera view
by highlighting its location.
3.9.1 Detecting Unattended Objects
To detect any unattended objects within the camera view, follow the steps below:
1. Click
the Configure button (No. 14, Figure 1-2), select Video Analysis, and select Object
Index/Monitor Setup. The Camera Applied Object Index/Monitor dialog box appears.
2. Select the desired cameras for the application.
3. Click the Configure button. The Video Object Setup dialog box (Figure 3-20) appears.
4. Click the Object Monitor tab. This dialog box appears.
Figure 3-32 Object Monitor
