6
1.1.1 Main Screen
Figure 1-2
The controls in the main screen:
No. Name Description
1 Camera Number
Indicates the camera number matching the port number in the GV video
capture card.
2 Camera Name Indicates the given camera name.
3 Date/Time Displays the current date and time.
4 Storage Space Indicates the remaining disk space.
5 Connection Indicates the connection status of remote applications.
6 PTZ Control Displays the PTZ control panel.
7 I/O Control Displays the I/O control panel.
8 TV-Out Displays the TV Quad control panel.
9 User-Defined Accesses other applications.
10 Location Name Indicates the GV-System’s name, usually named by its geographical location.
