8.3.1 Control Panel
A control panel is provided for control of the connected channel. To open the control panel, click the
Expand / Close button (No. 3, Figure 8-19) on top of the Single View viewer. To change the pages of
the control panel, click the Menu button (No. 2, Figure 8-19). You can also use the right and left arrow
buttons on the panel to change the pages.
The functions on the control panel:
Name Description
Information
Displays the current version, local time, host time and number of channels
currently accessing WebCam.
Video Displays the current video codec, resolution and data rate.
Audio
Displays audio data rates when the microphone and speaker devices are
enabled.
Preset Go Allows you to remotely move the PTZ to the preset points.
I/O Control
Provides a graphic display of the input and output devices from the
GV-System.
Alarm Notify
Displays the captured images by sensor triggers and/or motion detection.
See Alarm Notification later.
Camera Adjustment
Allows you to remotely adjust image quality by moving the slider to the desired
values.
POS/Wiegand
Allows you to view POS transactions or cardholder data along with live video.
If the monitoring is activated on the GV-System, double-clicking any
transaction items or cardholder data can have an instant playback.
People Count
Allows you to view the counts of Object Counting along with live view. Once
the counts are logged into the GV-System, In and Out counts will become
zero and the system will start counting those numbers again.
