178
The controls on the Panorama View Setup dialog box:
No. Name Description
1 Add Adds an image for automatic splicing.
2 Undo Cancels the settings.
3 Manual Setting Manually splices the images together.
4 Blending Makes the spliced images seamless.
5 Demo Displays the setup procedure.
6 Save Before Exit Saves the created panorama view and closes the dialog box.
7 Exit Closes the dialog box.
8 Preview Window Displays the selected source image or the spliced images.
9 Panorama Selection
Selects the panorama set for the images to be spliced together.
Clicks again to rename the panorama set.
10 Source Selects the source image to be spliced.
11 Selected Source Displays the selected image.
3.12.1 Creating a Panorama View
To stitch images from different cameras together, follow these steps:
1. Select one panorama set (No. 9, Figure 3-42) from the drop-down list. If you want to rename the
selected panorama set, type the name in the field.
2. Select one camera from the Source drop-down list (No. 10, Figure 3-42) and then click Manual
Setting (No.3, Figure 3-42). This dialog box appears.
Figure 3-43
