Configuring Main System
39
1
1.3.5 Turbo Mode
Turbo mode allows recording at the highest speed that GV-Combo A Card (GV-1120A, GV-1240A and
GV-1480A) can provide at the VGA and D1 resolutions.
Comparison for GV-Combo Card and GV-Combo A Card
Total Recording Rate (NTSC/PAL)
GV-1480 GV-1480A GV-1240 GV-1240A GV-1120 GV-1120A
VGA 120 / 100 fps 240 / 200 fps 120 / 100 fps 120 / 100 fps 80 / 70 fps 80 / 72 fps
D1 120 / 100 fps 240 / 200 fps 120 / 100 fps 120 /100 fps 80 / 70 fps 80 / 72 fps
Turbo VGA 416 / 400 fps 240 / 200 fps 120 / 100 fps
Turbo D1 352 / 320 fps 240 / 200 fps 120 / 100 fps
Note: When Turbo Mode is activated, the DSP (Real-Time Display) and TV-Out functions will be
disabled.
System Requirements
Following is the basic system requirements to activate the turbo mode.
Video Capture
Card
CPU RAM VGA HDD
GV-1120A x 1
Pentium 4, 3.0 GHz,
Dual Core
120 GB
GV-1240A x 1 Core 2 Duo, 3.0 GHz 160 GB
GV-1480A x 1 Core 2 Quad, 2.4 GHz
2 x 512 MB Dual
Channels
(Windows 2000 / XP)
2 x 1 GB Dual
Channels
(Windows Server
2003 / Vista)
ATI Radeon X1300
PCI-E /
NVIDIA n7300 PCI-E
320 GB
GV-1120A x 2 Core 2 Quad, 2.4 GHz 250 GB
GV-1240A x 2 Core 2 Quad, 2.8 GHz 320 GB
GV-1480A x 2 Core i7-920, 2.66 GHz
2 x 1 GB Dual
Channels
ATI Radeon X1300
PCI-E /
NVIDIA GeForce
7300 PCI-E
750 GB
