CCTV Camera Pros Geovision 8.5 Multicam Digital Surveillance System - Manual (Page 422)

404
8.6.12 Remote ViewLog
More than simply playing back recorded video/audio files, the Remote ViewLog function allows you to
have full access to the ViewLog features of the connected GV-System.
Note: To use the Remote ViewLog for the first time, you need to install the Remote ViewLog
components to the local PC. Install the components from the Surveillance System Software DVD, or
from the Download page (see Download Center later in this chapter).
1. On the Multi View window, click the ViewLog button (No. 8, Figure 8-34). The Connect to Remote
ViewLog Service dialog box appears.
2. Type the IP Address, ID and Password of the remote GV-System. Keep the default port as 5552,
or modify it if necessary.
3. In the Host Type field, select DVR.
4. Click the Connect button.
When the connection is established, you will see the video player ViewLog appears on the screen.
Then you can access all ViewLog features for playback.
