344
7.9 POS Live View
The POS Live View can display transaction data in a separate window instead of overlaying data on
the main screen. It features:
z Fast access to transaction data without opening System Log.
z The View is designed for high screen resolution of 1280 x 1024. When your monitor supports 1280
x 1024 and the main screen is set to 1024 x 768, you can juxtapose the main screen and the POS
Live View.
7.9.1 The POS Live View Window
On the main screen, click the ViewLog button, and then select POS Live View.
Figure 7-22
The controls in the POS Live View Window:
No. Name Description
1 Previous Transaction Goes to the previous transaction data.
2 Next Transaction Goes to the next transaction data.
3 Freeze
Suspends the current transaction data display. Clicking this button
again will restore to the live display.
4 Live View Menu Accesses the settings of POS Live View.
5 Exit Closes the POS Live View window.
