Remote Viewing
411
8
Note: If you select different network cards belonging to different networks for multicast, ensure the
receiving end of the multicast service is connected to the same network or IP sequence. For
example, if the IP address assigned for multicast is 192.168.2.x, the receiving end should also use
the network card of 192.168.2.x.
Network card selection at the receiving end
Receiving Audio Broadcast
1. If you like to receive audio broadcast from other hosts on the GV-System, select Receive
broadcast audio. By default the IP address is 224.1.1.3 and port number is 8400 to receive
broadcasting. Modify default values if necessary.
2. Click OK to start the WebCam server.
Now the GV-System can not only deliver the multicast stream but receive audio broadcast from other
hosts. Ensure a speaker is installed on the GV-System.
