114
4. The options in the dialog box may vary depending on camera brands.
„ Dual Stream: Sets the main stream to H.264 and the sub stream to MPEG4 for GV-IP
cameras. To see the firmware versions that support this function and the default resolutions
after the camera is added, refer to Appendix I.
„ Camera list: Select a camera number.
„ Port: Video streaming port number.
„ Stream number: You may have the option of single or dual streaming depending on camera
models.
„ Codec Type: You may have different codec options depending on camera models. If the
selected camera supports dual streaming, the preview codec and recording codec can be set
differently.
„ Resolution: You may select the different resolutions for preview and recording.
5. Click Apply. The IP camera is added to the list.
6. Right-click the camera and select Display position to map the IP camera to a channel on the
GV-System.
Figure 2-4
7. The Status column now should display “Connected”. Click OK.
To customize camera settings such as codec and frame rate, right-click the camera to see the list of
options. See Customizing IP Camera Settings section below for more details.
Tips: You can access the configuration interface of the connected IP device by right-clicking the IP
device and selecting Remote Camera Setting.
