Playing Back Video Files
213
4
The controls in the ViewLog window:
No. Name Description
1 Camera Name Indicates the given camera name.
2 Camera View Displays the playback video.
3 Arrow Switch Switches between List Mode and Line Mode. Sets up MDB filter.
4 Date Tree Displays date folders.
5 Display Option Specifies the event type to display in List Mode or Line Mode.
6 Video Event List Displays video events within a certain date folder.
7 Camera Select Sets a desired camera for display.
8 View Mode
Sets screen divisions: Single View, Panorama View, Quad View or
Multi View. Single View also includes these options: Standard,
Thumbnail, Mega Pixel (PIP), Mega Pixel (PAP), Geo Fisheye and
IMV1 Panomorph.
9 Advanced
Accesses basic search, advanced search and bookmark. Reloads
video event list.
10 Normal Displays or closes the Timeline or Video Event List.
11 Function Panel Provides various settings for ViewLog.
12 Slider Moves the slider to rewind or forward the video during playback.
13 Audio Playback Enables audio playback.
14 Playback Panel Contains typical playback control buttons.
15 Function Icons
A highlighted icon indicates an enabled function. From left to right are
the
wide angle lens dewarping , defogging function, stabilizer function,
reconnection to Remote ViewLog, A to B Mode, auto playing of next
events, the contrast and brightness function, the light enhancement
and equalization function, the sharpness and smoothness function
and the grayscale function.
16 Playback Speed Indicates the playback speed. x1 represents normal playback speed.
17 Time Display Indicates the time of the playback video.
18 Date Display Indicates the date of the playback video.
19 Exit Closes or minimizes the ViewLog window.
20 A to B Mode Plays repeatedly the set frames A to B.
21
Frame by Frame / Real
Time / Just Key Frame
Plays back video frame by frame, on real time or with just key frames.
