Configuring Main System
27
1
Mini-View for Remote Desktop: Squeezes all video channels into a single 320x240 view. Since
you may use Microsoft Remote Desktop (a feature that comes with Windows XP Professional
Edition) to set up the Main System through network, it is important to get smallest size possible
data to transfer over network.
After Mini-View for Remote Desktop is selected, restart the Main System and you can now switch
between the mini and normal view by clicking the Configure button (No.14, Figure 1-2), pointing
to A/V Setting and selecting Mini-View Switch.
Figure 1-17 Mini View
Default Screen Division: Select the number of screen division to display at startup.
Panel Resolution
~
From the drop-down list, select the resolution that best fits your computer monitor screen. For
the monitor display ratio supported by each panel resolution, see Appendix H.
~
Click
the Arrow button and select Activate Quad Enhanced to enable the enhanced screen
layout for the 8, 12 and 16 screen divisions. The layout on the left is the default layout; the
right is the enhanced layout.
Figure 1-18
