Video Analysis
147
3
3.3.3 Tracking in PAP View
The PAP (Picture-and-Picture) View with Digital Object Tracking can create split video effects with up
to 7 close-up views on moving objects.
1. On the main screen, click the desired camera name label and select PAP View.
2. The screen automatically switches to one division, and a row of inset windows appears around the
live view screen. The number of inset windows is based on the number set for Max Number of
Tracked Objects.
Figure 3-16
3. When a moving object enters the camera view, it will be highlighted with a navigation box to help
you track the object. An inset window will also display the magnified image of the tracked object.
4. You could also draw the box to select a focus area, and this selected area is immediately reflected
in one inset window. Up to (7 - Max Number of Tracked Objects) boxes can be drawn for focus
areas. For instance, you can draw 5 boxes to be focus areas if you select 2 for the Max Number of
Tracked Objects. See Setting Digital Object Tracking earlier in this chapter.
• To delete a focus area, right-click a drawn box, select Focus Area of PAP Mode and select
Delete.
• To add another focus area when less than seven boxes are drawn, right-click the image,
select Mega Pixel Setting, and select Enable Add-Focus-Area-Mode. Then draw a box on
the image.
