Point-of-Sale (POS) Application
337
7
7.5 POS Field Filter
POS Field Filter allows you to create a column for a transaction item in System Log. It further filters the
transaction conditions based on your criteria, and displays the results under the created column. To set
up the function, follow these steps:
1. On the main screen, click the Configure button (No. 14, Figure 1-2), select Accessories, select
POS Application Setting, and select POS Field Filter Setup. This dialog box appears.
Figure 7-15 POS Capture Data Setting
2. Click the New button and select Caption Data. This dialog box appears.
Figure 7-16 Setting search criteria
