The controls in the Remote E-Map window:
No. Name Description
1 Login Click to login up to 500 hosts.
2 Host Information
Click to view the information of incoming events upon motion detected
and I/O devices triggered.
3 Previous Click to go to the previous E-Map file.
4 Home Click to back to the top of the tree view.
5 Next Click to go to the next E-Map file.
6 ViewLog Click to access the Remote ViewLog function.
7 Configure Click to configure the Remote E-Map.
8 Tree List The list displays all created E-Map files and folders.
9 IP Address Displays the IP Address of the connected host.
10 Blinking Icon The blinking icon represents a triggered camera or I/O device.
11 Output Icon Click to manually force the output device.
12 Camera/Dome Icon
Click to view the live video associated with that camera/dome. Up to
16 live videos can be accessed simultaneously.
