Operating Instructions Model 6200E Instruction Manual
74 M6200E Rev: A1
6.7.5. Independent Range Mode (IND)
Selecting independent range mode allows the A1 and A2 outputs to be configured with different
measurement ranges. The analyzer software calls these two ranges LOW and HIGH. The LOW
range setting corresponds with the analog output labeled A1 on the rear panel of the instrument.
The HIGH range setting corresponds with the A2 output. While the software names these two
ranges LOW and HIGH, they do not have to be configured that way.
Also, in this mode the RANGE Test function displayed on the front panel during SAMPLE mode will
be replaced by two separate functions, RANGE1 & RANGE2.
• LOW range = RANGE1 = Range value for output A1 = 0-1500 ppb H
2
S.
• HIGH range = RANGE2 = Range value for output A2 = 0-500 ppb H
2
S.
For M6200E’s configured to measure both SO
2
and H
2
S in multigas measurement mode:
• LOW range = RANGE1 = Range value for output A1= 0-1500 ppm SO
2
.
• HIGH range = RANGE2 = Range value for output A2 =0-1000 ppm H
2
S.
To select the independent reporting range mode and set the upper measurement limits for the two
outputs, press:
SAMPLE ENTER SETUP PASS : 818
8 1 8 ENTR EXIT
SETUP X.X PRIMARY SETUP MENU
CFG DAS RNGE PASS CLK MORE EXIT
SETUP X.X RANGE CONTROL MENU
MODE SET UNIT EXIT
SETUP X.X RANGE MODE: SNGL
SNGL IND AUTO ENTR EXIT
SETUP X.X RANGE CONTROL MENU
MODE SET UNIT EXIT
SETUP X.X HIGH RANGE: 500.0 Conc
0 0 5 0 0 .0 ENTR EXIT
SETUP X.X LOW RANGE : 500.0 Conc
0 0 1 0 0 .0 ENTR EXIT
SETUP X.X RANGE CONTROL MENU
MODE SET UNIT EXIT
EXIT Returns
to the Main
SAMPLE Display
SETUP X.X RANGE MODE: DUAL
SNGL IND AUTO ENTR EXIT
Toggle the
Numeral Keys
to set the upper
limit of each
range.
SAMPLE RANGE = 500.0 PPB H2S =XXX.X
< TST TST > CAL SETUP
NOTE
In INDEPENDENT range mode the two reporting ranges have separate slopes and offsets
for computing concentration and MUST be independently calibrated.
