3. GETTING STARTED
3.1. Unpacking and Initial Setup
CAUTION
To avoid personal injury, always use two persons to lift and carry the
Model 6200E.
1. Inspect the received packages for external shipping damage. If damaged, please advise the
shipper first, then Teledyne Analytical Instruments.
2. Included with your analyzer is a printed record (Form number 04551) of the final performance
characterization performed on your instrument at the factory. This record is an important
quality assurance and calibration record for this instrument. It should be placed in the quality
records file for this instrument.
3. Carefully remove the top cover of the analyzer and check for internal shipping damage.
• Remove the set screw located in the top, center of the rear panel
• Remove the screws fastening the top cover to the unit (four per side).
• Lift the cover straight up.
NOTE
Printed circuit assemblies (PCAs) are static sensitive. Electro-static discharges (ESD),
too small to be felt by the human nervous system, are large enough to destroy sensitive
circuits.
Before touching PCAs, read Chapter 12 of this manual and follow the procedure
described there for avoiding damage to your instrument due to ESD.
CAUTION
Never disconnect electronic circuit boards, wiring harnesses or
electronic subassemblies while the unit is under power.
4. Inspect the interior of the instrument to make sure all circuit boards and other components
are in good shape and properly seated.
5. Check the connectors of the various internal wiring harnesses and pneumatic hoses to make
sure they are firmly and properly seated.
