Operating Instructions Model 6200E Instruction Manual
62 M6200E Rev: A1
To view the TEST Functions press the following Key sequence:
1
Only appears if IZS option is
installed.
2
Only appears if analog output A4
is actively reporting a test function.
3
Shown as they appear when analyzer
is in H
2
S mode. In SO
2
mode appear as SO2 STB, SO2 OFFS &
SO2 SLOPE. In multigas mode, both versions appear.
RANGE
H2S STB 3
PRES
SAMP FL
PMT
NORM PMT
UV LAMP
LAMP RATIO
STR. LGT
DARK PMT
DARK LAMP
H2S SLOPE
3
H2S OFFS 3
HVPS
RCELL TEMP
BOX TEMP
PMT TEMP
IZS TEMP
1
TEST 2
TIME
SAMPLE RANGE = 500.0 PPB NOX = X.X
< TST TST > CAL SETUP
Refer to
Section
6.2.1 for
definitions
of these
test
functions.
Toggle keys to
scroll through list of functions
Figure 6-2 Viewing M6200E TEST Functions
NOTE
A value of “XXXX” displayed for any of the TEST functions indicates an out-of-range
reading or the analyzer’s inability to calculate it.
All pressure measurements are represented in terms of absolute pressure. Absolute,
atmospheric pressure is 29.92 in-Hg-A at sea level. It decreases about 1 in-Hg per 300 m
gain in altitude. A variety of factors such as air conditioning and passing storms can
cause changes in the absolute atmospheric pressure.
