Optional Hardware and Software Model 6200E Instruction Manual
54 M6200E Rev: A1
Figure 5-5: M6200E Ethernet Card
Rear Panel
(as seen from inside)
CPU
Card Ethernet
Card
Female RJ-45
Connector
RE-232
Connector To
Motherboard
LNK LED
ACT LED
TxD LED
RxD LED
Interior View Exterior View
Figure 5-6: M6200E Rear Panel with Ethernet Installed
This option can be installed in conjunction with the RS-2323 multidrop (option 62) allowing the
instrument to communicate on both types of networks simultaneously. For more information on
using and setting up this option see Section 6.10.6)
