Model 6200E Instruction Manual Specifications, Approvals and Warranty
M6200E Rev: A1 17
2. SPECIFICATIONS, APPROVALS AND
WARRANTY
2.1. Specifications
Table 2-1: Model 6200E Basic Unit Specifications
Min/Max Range
(Physical Analog Output) In 1 ppb increments from 50 ppb to 20 000 ppb, independent ranges or auto
ranging
Measurement Units ppb, ppm, µg/m3, mg/m3 (user selectable)
Zero Noise 1 0.2 ppb RMS
Span Noise 1 0.2 ppb RMS
Lower Detectable Limit 2 0.4 ppb RMS
Zero Drift (24 hours) <0.5 ppb
Zero Drift (7 days) 1 ppb
Span Drift (7 Days) <0.5% FS
Linearity 1% of full scale
Precision 0.5% of reading 1
Temperature Coefficient < 0.1% per o C
Voltage Coefficient < 0.05% per V
Rise/Fall Time 1 95% in <100 sec
Sample Flow Rate 650cc/min. ±10%
Temperature Range 5-40oC
Humidity Range 0 - 95% RH, non-condensing
Dimensions H x W x D 7" x 17" x 23.5" (178 mm x 432 mm x 597 mm)
Weight, Analyzer
(Basic Configuration) 45 lbs (20.5 kg) w/internal pump
AC Power Rating 100 V, 50/60 Hz (1.7 A / 2.3 A surge);
115 V, 60 Hz (1.5 A / 2.0 A surge);
220 – 240 V, 50/60 Hz (.0.75 A \ 1.0 A surge)
Environmental Installation category (over-voltage category) II; Pollution degree 2
Analog Outputs Three (3) Outputs
Analog Output Ranges 100 mV, 1 V, 5 V, 10 V, 2-20 or 4-20 mA isolated current loop.
All Ranges with 5% Under/Over Range
Analog Output Resolution 1 part in 4096 of selected full-scale voltage
Status Outputs 8 Status outputs from opto-isolators
Control Inputs 6 Control Inputs, 3 defined, 3 spare
Serial I/O One (1) RS-232; One (1) RS-485 (2 connecters in parallel)
Baud Rate : 300 – 115200: Optional Ethernet Interface
Certifications EN61326 (1997 w/A1: 98) Class A, FCC Part 15 Subpart B Section
15.107 Class A, ICES-003 Class A (ANSI C63.4 1992) & AS/NZS
3548 (w/A1 & A2; 97) Class A
IEC 61010-1:90 + A1:92 + A2:95,
For indoor use at altitudes ≤ 2000m only
1 As defined by the USEPA.
2 Defined as twice the zero noise level by the USEPA.
