Model 6200E Instruction Manual Operating Instructions
M6200E Rev: A1 151
SETUP X.X SECONDARY SETUP MENU
COMM VARS DIAG ALRM EXIT
SAMPLE ENTER SETUP PASS : 818
8 1 8 ENTR EXIT
SETUP X.X PRIMARY SETUP MENU
CFG DAS RNGE PASS CLK MORE EXIT
SAMPLE RANGE = 500.0 PPB H2S =XXX.X
< TST TST > CAL SETUP
SETUP X.X COMMUNICATIONS MENU
ID HESN COM1 COM2
EXIT
SETUP X. HESSEN VARIATION: TYPE 1
SET> EDIT EXIT
SETUP X.X HESSEN VARIATION: TYPE 1
TYE1 TYPE 2 ENTR EXIT
SETUP X.X HESSEN VARIATION: TYPE 2
PREV NEXT OFF ENTR EXIT
Press to change
protocol type.
ENTR key accepts the
new settings
EXIT key ignores the
new settings
NOTE
While Hessen Protocol Mode can be activated independently for COM1 and COM2, The
TYPE selection affects both Ports.
6.12.4.5. Setting The Hessen Protocol Response Mode
The Teledyne Analytical Instruments’ implementation of Hessen Protocol allows the user to choose
one of several different modes of response for the analyzer.
Table 6-28: M6200E Hessen Protocol Response Modes
MODE ID MODE DESCRIPTION
CMD This is the Default Setting. Reponses from the instrument are encoded as the traditional
command format. Styel and format of responses depend on exact coding of the initiating
command.
BCC Responses from the instrument are always delimited with (at the beginning of the
response, (at the end of the response followed by a 2 digit Block Check Code
(checksum), regardless of the command encoding.
TEXT Responses from the instrument are always delimited with at the beginning and the end
of the string, regardless of the command encoding.
To Select a Hessen response mode, press:
