APPENDIX A-2: Setup Variables For Serial I/O, Revision A.1
Model 6200E Instruction Manual
286
M6200E Rev A.1
SETUP VARIABLE
NUMERIC
UNITS
DEFAULT
VALUE
VALUE RANGE
DESCRIPTION
RS232_MODE
BitFlag
0
0–65535
RS-232 COM1 mode flags. Add
values to combine flags.
1 = quiet mode
2 = computer mode
4 = enable security
16 = enable Hessen protocol
5
32 = enable multi-drop
64 = enable modem
128 = ignore RS-232 line errors
256 = disable XON / XOFF support
512 = disable hardware FIFOs
1024 = enable RS-485 mode
2048 = even parity, 7 data bits, 1
stop bit
4096 = enable command prompt
BAUD_RATE
— 19200 300,
1200,
2400,
4800,
9600,
19200,
38400,
57600,
115200
RS-232 COM1 baud rate. Enclose
value in double quotes (“) when
setting from the RS-232 interface.
MODEM_INIT
— “AT
Y0
&D0 &H0
&I0
S0=2
&B0 &N6
&M0 E0
Q1 &W0”
Any character in
the allowed
character set. Up
to 100 characters
long.
RS-232 COM1 modem initialization
string. Sent verbatim plus carriage
return to modem on power up or
manually. Enclose value in double
quotes (“) when setting from the RS-
232 interface.
RS232_MODE2
BitFlag
0
0–65535
RS-232 COM2 mode flags.
(Same settings as RS232_MODE.)
BAUD_RATE2
— 19200 300,
1200,
2400,
4800,
9600,
19200,
38400,
57600,
115200
RS-232 COM2 baud rate. Enclose
value in double quotes (“) when
setting from the RS-232 interface.
MODEM_INIT2
— “AT
Y0
&D0 &H0
&I0
S0=2
Any character in
the allowed
character set. Up
to 100 characters
RS-232 COM2 modem initialization
string. Sent verbatim plus carriage
return to modem on power up or
manually. Enclose value in double
