NOTE
Sending an iDAS configuration to the analyzer through its COM ports will replace the
existing configuration and will delete all stored data. Back up any existing data and the
iDAS configuration before uploading new settings.
6.11.2.1. Viewing iDAS Data and Settings
iDAS data and settings can be viewed on the front panel through the following keystroke sequence.
SAMPLE RANGE = 500.0 PPB H2S =XXX.X
< TST TST > CAL SETUP
SETUP X.X CONC : DATA AVAILABLE
NEXT VIEW EXIT
SETUP X.X PNUMTC : DATA AVAILABLE
PREV NEXT VIEW EXIT
SETUP X.X CALDAT : DATA AVAILABLE
PREV VIEW EXIT
SETUP X.X 00:00:00 S2SLP1=0.000
PV10 PREV PRM> EXIT
SETUP X.X 00:00:00 S2SCN1 =0.0 PPM
PV10 PREV NEXT NX10 PRM> EXIT
SETUP X.X 00:00:00 SMPFLW=000.0 cc / m
PRM> EXIT
SETUP X.X DATA ACQUISITION
VIEW EDIT EXIT
SETUP X.X PRIMARY SETUP MENU
CFG
DAS RNGE PASS CLK MORE EXIT
VIEW KEYPAD FUNCTIONS
KEY FUNCTION
Moves to the next Parameter
PRM> Moves to the previous
Parameter
NX10 Moves the view forward 10
data points/channels
NEXT Moves to the next data
point/channel
PREV Moves to the previous data
point/channel
PV10 Moves the view back 10 data
points/channels
Keys only appear as needed
EXIT will return to the
main SAMPLE Display.
SAMPLE ENTER SETUP PASS : 818
8 1 8 ENTR EXIT
