Model 6200E Instruction Manual Operating Instructions
M6200E Rev: A1 63
6.2.2. Warning Messages
The most common instrument failures will be reported as a warning on the analyzer’s front panel
and through the COM ports. Section 11.1.1 explains how to use these messages to troubleshoot
problems. Section 3.2.3 shows how to view and clear warning messages. Table 6-3 lists all warning
messages for the current version of software.
Table 6-3: List of Warning Messages
MESSAGE MEANING
ANALOG CAL WARNING The instruments A/D circuitry or one of its analog outputs is not
calibrated.
AZERO WRN XXX.X MV The reading taken during the auto-zero cycle is outside of
specified limits. The value XXX.X indicates the auto-zero reading
at the time of the warning.
BOX TEMP WARNING The temperature inside the M6200E chassis is outside the
specified limits.
CANNOT DYN SPAN Remote span calibration failed while the dynamic span feature was
set to turned on
CANNOT DYN ZERO Remote zero calibration failed while the dynamic zero feature was
set to turned on
CONFIG INITIALIZED Configuration was reset to factory defaults or was erased.
CONV TEMP WARNING The temperature of the H
2
S Æ SO
2
catalytic converter is outside its
optimal operating range.
DARK CAL WARNING Dark offset above limit specified indicating that too much stray
light is present in the sample chamber.
DATA INITIALIZED iDAS data storage was erased.
FRONT PANEL WARN Firmware is unable to communicate with the front panel.
HVPS WARNING High voltage power supply for the PMT is outside of specified
limits.
IZS TEMP WARNING On units with IZS options installed: The permeation tube
temperature is outside of specified limits.
PMT DET WARNING PMT detector output outside of operational limits.
PMT TEMP WARNING PMT temperature is outside of specified limits.
RCELL PRESS WARN Sample chamber pressure is outside of specified limits.
RCELL TEMP WARNING Sample chamber temperature is outside of specified limits.
REAR BOARD NOT DET The CPU is unable to communicate with the motherboard.
RELAY BOARD WARN The firmware is unable to communicate with the relay board.
SAMPLE FLOW WARN The flow rate of the sample gas is outside the specified limits.
SAMPLE PRESS WARN Sample pressure outside of operational parameters.
SYSTEM RESET The computer was rebooted.
UV LAMP WARNING The UV lamp intensity measured by the reference detector reading
too low or too high
