APPENDIX A-2: Setup Variables For Serial I/O, Revision A.1 Model 6200E Instruction Manual
284 M6200E Rev A.1
SETUP VARIABLE NUMERIC
UNITS
DEFAULT
VALUE
VALUE RANGE DESCRIPTION
DWELL_TIME Seconds 1 0.1–10 Dwell time before taking each
sample.
FILT_SIZE Samples 240 1–480 Moving average filter size.
FILT_ASIZE Samples 20 1–100 Moving average filter size in adaptive
mode.
FILT_DELTA PPB 20 1–100 Absolute change to trigger adaptive
filter.
FILT_PCT % 5 1–100 Percent change to trigger adaptive
filter.
FILT_DELAY Seconds 180 0–300 Delay before leaving adaptive filter
mode.
FILT_ADAPT — ON OFF, ON ON enables adaptive filter; OFF
disables it.
DIL_FACTOR — 1 0.1–1000 Dilution factor if dilution enabled with
FACTORY_OPT variable.
USER_UNITS — PPB PPB,
PPM,
UGM,
MGM
Concentration units for user
interface. Enclose value in double
quotes (“) when setting from the RS-
232 interface.
LAMP_CAL mV 3500 1000–5000 Last calibrated UV lamp reading.
LAMP_GAIN — 0.9 0.5–1.5 UV lamp compensation attenuation
factor.
TEMPCO_GAIN — 0.15 0.01–10 Temperature coefficient attenuation
factor for pressure readings.
SLOPE_CONST — 8 0.1–10 Constant to make visible slope close
to 1.
DARK_ENABLE — ON OFF, ON ON enables PMT/UV dark calibration;
OFF disables it.
DARK_FREQ Minutes 30 0.1–1440 Dark calibration period.
DARK_PRE_DWELL Seconds 10 1–60 Dwell time after closing dark shutter
or turning off lamp or selecting
preamp range.
DARK_POST_DWELL Seconds 10 1–180 Dwell time after opening dark shutter
or turning on lamp.
DARK_SAMPLES Samples 5 1–10 Number of dark samples to average.
DARK_FSIZE Samples 2 1–100 Dark offset moving average filter
size.
DARK_LIMIT mV 200 0–1000 Maximum dark offset allowed.
SO2_SPAN1 Conc 400 0.1–50000 Target SO
2
concentration during span
calibration of range 1.
SO2_SPAN2 Conc 400 0.1–50000 Target SO
2
concentration during span
calibration of range 2.
SO2_SLOPE1 PPB/mV 1 0.25–4 SO
2
slope for range 1.
SO2_SLOPE2 PPB/mV 1 0.25–4 SO
2
slope for range 2.
SO2_OFFSET1 mV 0 -1500–1500 SO
2
offset for range 1.
SO2_OFFSET2 mV 0 -1500–1500 SO
2
offset for range 2.
