3.2 Initial Setting

79

Operation Pattern

({ : Available for Setting)

No. Setting Item Setting Range

(Set in delivery)

Description

0

1

2

3

4

5

8 Output

Signal

Selection

0 to 2

(0)

If “Use” is selected in No. 5 Servo Control,

select the combination of the used output

signals considering the operation pattern.

Select 0 if “Not to Use” is selected.

• For Operation Patterns 0 to 2 and 5,

select from the combinations 0 to 2 below.

0 : OUT2 = HEND

OUT3 = *ALM

(No servo-on signal output)

1 : OUT2 = SV

OUT3 = *ALM

2 : OUT2 = HEND

OUT3 = SV

• For Operation Patterns 3 and 4,

select from the combinations 0 and 1

below.

0 : OUT3 = *ALM

(No servo-on signal output)

1 : OUT3 = SV

[Refer to Section 3.8.2 for the details.]

{

{

{

{

{

{
