Chapter 1 Specifications Check
24
1.4 Specifications for each Fieldbus
1.4.1 Specifications of DeviceNet Interface
Item Specification
DeviceNet2.0
Group 2 Dedicated Server Communication Protocol
Network-Powered Insulation Node
Baud Rate Automatically follows the master
Communication System Master-Slave System (Polling)
Number of Occupied Channels Refer to 3.4.1 PLC Address Construction by each Operation Mode
Number of Occupied Nodes 1 Node
Baud Rate
Max. Network
Length
Total Branch Line
Length
Max. Branch Line
Length
500kbps 100m 39m
250kbps 250m 78m
Communication Cable Length (Note 2)
125kbps 500m 156m
6m
Communications Cable Use the dedicated cable.
Connector (Note 1) MSTBA2.5/5-G-5.08-ABGY AU (Manufactured by PHOENIX CONTACT or equivalent)
Consumption Current of
Communication Power Supply
60mA
Communication Power Supply 24V DC (Supplied from DeviceNet)
Note 1 The cable-side connector is a standard accessory. (PHOENIX CONTACT MSTB2.5/5-ST-5.08ABGY AU)
Note 2 For T branch communication, refer to the Instruction Manuals for the master unit and programmable controller (PLC)
to be mounted.
1.4.2 Specifications of CC-Link Interface
Item Specification
Communication Protocol CC-Link ver1.1 or ver2
Station Type Remote Device Station (MAX. four stations occupied)
Baud Rate 10M/5M/2.5M/625k/156kbps
Communication System Broadcast Polling System
Number of occupied stations Refer to 3.4.1 PLC Address Construction by each Operation Mode
Baud Rate (bps)
10M 5M 2.5M 625k 156k Communication Cable Length (Note 2)
Total Cable Length (m) 100 160 400 900 1200
Communications Cable Apply the dedicated cable
Connector (Note 1) MSTBA2.5/5-G-5.08-ABGY AU (Manufactured by PHOENIX CONTACT or equivalent)
Note 1 The cable-side connector is a standard accessory. (PHOENIX CONTACT MSTBA2.5/5-ST-5.08-ABGY AU)
Note 2 For T branch communication, refer to the Instruction Manuals for the master unit and PLC to be mounted.
