3.4 Fieldbus

Type

Address Map

118

(ON = Applicable bit is “1”, OFF = Applicable bit is “0”)

Signal Type

Bit

Symbol

Description

Details

Current

Position

32

bits

Data

32-bit signed integer indicating the current position

Unit: 0.01mm

(Example) If 10.23mm, input 000003FF

H

(1023mm in

decimal system).

(Note) Negative numbers are two’s implement.

3.8.1 (22)

Command

Current

32

bits

Data

32-bit integer

The electrical current presently specified by a command

is indicated.

The setting unit is mA.

This resistor makes an output in hexadecimal numbers.

(Example) Reading: 000003FF

H

= 1023 (Decimal

number) = 1023mA

3.8.1 (22)

Current

Speed

16

bits

Data

16-bit integer

The current speed is indicated.

Unit: 1.0mm/sec or 0.1mm/sec.

A change of the unit is to be conducted on Gateway

Parameter Setting Tool.

(Example) Reading: 03FF

H

= 1023 (Decimal number) =

10.23mm/sec

(Note) Negative numbers are two’s implement.

3.8.1 (22)

Alarm

Code

16

bits

Data

16-bit integer

The simple alarm code (refer to Chapter 6

Troubleshooting) is output while an alarm is issued (ALM

of Status Signal is ON).

3.8.1 (22)

b15

EMGS This signal turns ON during an emergency stop

3.8.1 [2]

b14

CRDY

This signal turns ON when the controller is standing by.

3.8.1 [1]

b13

ZONE2 “ON” for the current position within the zone 2 set range

The zone range setting is necessary for the parameter.

b12

ZONE1 “ON” for the current position within the zone 1 set range

The zone range setting is necessary for the parameter.

3.8.1 [11]

b11

b10

b9

Cannot be used.

b8

MEND

This signal turns ON at either of positioning complete,

home return complete, pressing complete or pressing

failure, and turns OFF at movement start.

It is OFF before movement.

3.8.1 [19]

b7

ALML

Light error alarm output

It turns ON when a message level error is issued.

3.8.1[20]

b6

Cannot be used.

b5

PSFL

This signal turns ON when the actuator missed the load

in push-motion operation.

3.8.1 [18]

b4

SV

This signal turns ON when operation standby is complete

(Servo is ON).

3.8.1 [5]

b3

ALM

This signal is ON while an alarm is generated.

3.8.1 [3]

b2

MOVE This signal is ON while in movement.

3.8.1 [8]

b1

HEND

This signal turns ON at home return complete and is kept

unless the home position is lost due to a fact such as an

alarm.

3.8.1 [6]

P

LC

In

pu

t

Status

Signal

b0

PEND

This signal turns ON at positioning complete and is kept

ON during a stop with the servo ON, but does not turn

ON when pressing operation is failed.

3.8.1 [9]
