Krystal 4300 Reference 11-23
Combiner Menus
The Secondary ISO feature makes it possible to create two separate com-
bined outputs simultaneously. The figure below shows Stage 3 isolated to
the secondary output, making combined channels 1 and 2 appear on the
primary output, and combined channels 3 and 4 appear on the secondary
output.
Input
Press MODIFY to select INPUT to display the following menu. The Camera
channel must be delegated to change input controls.
From this menu you control the combiner input assignments. You map
logical channels (1, 2, 3, 4) to combiner inputs A, B, C, and D in any order
desired. Note that the A, B, C, D letters do not indicate physical Krystal
Video Processor channels. The actual channel being assigned will be what-
ever channel has been acquired for control by that Krystal logical channel.
COMBINER CONTROL
Displ: Camera
Re: 1 - Register
KF: 1 of 5
Time: [0.00]
Primary
2ndary
INPUT
OUTPUTS
CHANNEL
COMBINING
NONE
STAGE 3
STAGE 2
STAGE 1
CHANNEL 4
CHANNEL 3
CHANNEL 2
CHANNEL 1
OFF
ON
MODIFY SECONDARY
OUTPUT
SECONDARY
ISO
COMBINER
BACKGROUND >
A: Ch 1
B: Ch 2
C: Ch 3
D: Ch 4
Stage 3
D
Stage 2
D
Stage 1
D
Displ: Camera
Re: 1 - Register
KF: 1 of 5
Time: [0.00]
Primary
2ndary
INPUT
OUTPUTS
CHANNEL
COMBINING
MODIFY SELECT/
SCROLL
ASSIGN
CHAN 1
ASSIGN
CHAN 2
ASSIGN
CHAN 4
ASSIGN
CHAN 3
CLEAR
ASSIGNMT
SCROLL
COMBINER CONTROL
A: Ch 1
B: Ch 2
C: Ch 3
D: Ch 4
Stage 3
D
Stage 2
D
Stage 1
D
Combiner Input Logical Channel
INPUT ASSIGNMENTS:
A: Channel 1
B: Channel 2
C: Channel 3
D: Channel 4
