Fieldware for the Legacy 6000
Software Version 2.11
Chapter 3 - Real-time Setup 3-15
Performing a Calibration
Granular & Seeder Static Calibration
The Granular Static Calibration process is a stationary calibration for a granular sensor. There are
two calibration modes to choose from, Static or InField, only one is needed for accurate calibration.
Static calibrations does not involve movement of the vehicle and can be repeated very easily to
ensure an accurate calibration.
1. Fill the machine’s tank with a know amount of
weighed product. From the ARM Launcher page select
the Calibration button by using the function key or by
highlighting Calibration and pressing the green enter
button.
2. From the Calibration page select the PCM - Granu-
lar option from the pick list in the middle of the screen.
Press the green forward arrow to continue to the next
calibration step.
3. From the Calibration Mode page select Static from
the pick list in the middle of the screen. Press the
green forward arrow key to continue to the next cali-
bration step.
- Static - Does not require the vehicle to move. This is
a stationary test.
- In Field - Involves driving in a field, simulating a real
time application.
4. Enter the application rate that will be used later in a
real time application for best results. Press the green
forward arrow key to continue to the next calibration
step.
5. Enter the product density. Press the green forward
arrow to continue to the next calibration step.
