B-4
Appendix B - Creating a Calibration Table
Fieldware for The Legacy 6000
Software Version 2.11
Creating a Calibration Table Using the Legacy 6000
• From PCM Setup navigate to the Primary Sensor page and select the tools button.
• Use the Down arrow to highlight Cal# Basis and press enter.
• Name the Cal# Basis, this will be the Name of the Cal Table. Once a name has been estab-
lished continue forward through PCM Setup and apply the settings.
• Advance to the ARM Launcher page and select the Calibration button. Choose the calibration
procedure for the application and press the green forward arrow.
• Because Cal# Basis is not NONE in PCM Setup, a new screen appears in calibration. This
screen will have the same name that was entered for Cal# Basis in PCM Setup. From this
screen name a parameter to be calibrated. In the example above GATE HEIGHT was the Cal
Table name and each parameter was described in inches (1 INCH, 2 INCH, ...etc.)
• Proceed through calibration, once calibrated name the next parameter in the Cal Table and
Calibrate. Repeat this step for each Cal Table parameter.
NOTE: If GATE HEIGHT is used for the Cal# Basis name in PCM Setup, Midwest Technologies
has pre-named the parameters in Calibration 1 INCH - 12 INCH.
