Fieldware for the Legacy 6000
Software Version 2.11
Chapter 3 - Real-time Setup 3-31
ARM Setup
ARM Setup
ARM Setup handles all data file names as well as a few product application parameters. To run
ARM Setup, select the ARM Setup tab in the ARM Launcher page (Figure 3-13). This brings up
the Main ARM Setup page (Figure 3-13) right image.
When ARM is first started, it asks the operator to enter/select a job name (see "Starting a Job" on
page 2-4). This job name is used to automatically name all of the job related files.
No PCMCIA Card Selected
If you have the PC Card setting in Console setup set to NO, the ARM Setup main page looks
slightly different. All ARM setup items related to files and naming files are omitted from the main
page.
Running the ARM setup Wizard
The Main ARM Setup page is the page seen when ARM Setup is first entered (Figure 3-13) right
image. The ARM Setup page contains every setup item in a list. From this list each ARM Setup
item can be edited individually or the ARM Setup Wizard can be run. The top item in the list is the
Setup Wizard. To run the Setup Wizard, highlight in the main list and press the
enter key. The Setup Wizard will walk through the entire ARM Setup item list.
Table 3-4 lists all of the ARM Setup items and their descriptions.
Figure 3-13: The ARM Launcher / ARM Setup Page
