2-14 Chapter 2 - Getting Started
Implement Setup
Fieldware for the Legacy 6000
Software Version 2.11
Setting the Section to Switch Assignment
The Section to Switch page allows you to assign a physical boom switch to the current Swath Sec-
tion. This allows the control of individual sections.
Entering the Section Width
The Section Width page is where the width of a section is entered. When the correct section width
is entered, press the forward arrow button to move to the next setup page.
If there is more than one section for a swath, Implement setup will alternate between Section to
Switch Assignment and Section Width until all sections have been completed.
Figure 2-18: The Section to Switch Assignment Page
Figure 2-19: The Section Width Page
