1-2 Chapter 1 - System Introduction
System Introduction
Fieldware for The Legacy 6000
Software Version 2.11
System Introduction
The Legacy 6000 system allows the control of all product types, plus GPS mapping, guidance, and
data collection in a single console. Replacing multiple consoles in the cab with one robust system,
Mid-Tech's Legacy 6000 sets a new standard for control systems of the future.
The Legacy 6000 runs Fieldware software in a Windows CE environment, an extremely depend-
able and stable operating system. Operation is intuitive with on-screen menu choices and
prompts. An on-board help menu is built in. The heart of the Legacy console is an Intel processor
operating at 206 Megahertz for maximum efficiency.
System Features
System features include:
• Product control with optional integrated guidance
• Four guidance modes, Ignore Headland, Curved, Parallel and Center Pivot.
• Single console in the cab with a single cable connection to the console
• Simplifies operation of product control and GPS record keeping
• Works with Mid-Tech's Swath XL lightbar
• Comes fully loaded with “Fieldware for the Legacy 6000” software
• Precise control of liquid & dry products on common delivery systems
• Flow- or pressure-based liquid control with multiple sensor inputs for each product
• Handles up to 20 individual boom sections and 4 swaths
• Up to 5 application rates per product can be preset and accessed on the go
• Supports granular application control using 2 rate sensors per product
• Compatible with most sensors, valves, and D.C. drives
• Operates bi-directional or PWM valves
• Operator selectable gain settings for control valves
• Adding additional product control is easy
• Single high speed bus cable coming into cab
• Automatic Boom shutoff
• Mapper option for mapping points, lines, and polygons
