Fieldware for The Legacy 6000
Software Version 2.11
A-1
Appendix A - PCM Favorites Settings
Appendix A - PCM Favorites Settings
LIQFLOW-A GRANSERVO-A
Favorite: LIQFLOW-A Favorite: GRANSERVO-A
Application Liquid Application Granular
Application name MAIN_TANK Application name MAIN_BIN
Configuration Standard Configuration Standard
PCM link None PCM link None
Drive Type Servo Drive Type Servo
Gain 3 Gain 3
Start Up Drive 20% Start Up Drive 20%
Master Switch Hold Master Switch Close
Implement Status Close Implement Status Close
Valve Delay 1.00s Valve Delay 1.00s
Valve Location In-Line Valve Location In-Line
Units gal/ac Units lb/ac
Control Basis Area Control Basis Area
Primary Sensor Flowmeter Primary Sensor Granular
Input A Input A
Sensor Name FLOWMETER Sensor Name CONVEYOR_SENSOR
Calibration # 153.1 pul/gal Calibration # 400 pul/ft3
Cal# Basis NONE Cal# Basis NONE
Secondary Sensor None Secondary Sensor None
Monitor 1 Pressure Analog Monitor 1 Shaft
Input F Input D
Sensor Name PRESSURE_SENSOR Sensor Name SPINNER SPEED
Alarm Units psi Calibration # 2.0 pul/r
Min. Alarm 15 Alarm units rpm
Max. Alarm 60 Min. Alarm Off
Alarm Delay 3s Max. Alarm Off
Sensor Output 0-5.0v Alarm Delay 10s
Monitor 2 None Monitor 2 None
Monitor 3 None Monitor 3 None
Montior 4 None Montior 4 None
