Fieldware for The Legacy 6000

Software Version 2.11

Chapter 1 - System Introduction

1-13

Mid-Tech CAN Bus System Overview

Product Control Module

Figure 1-9: Power Control Module Harness

PCM Cable Options

Sensor Inputs

Part Number

A

B

C

D

E

F

CAN

PWR

Valve

Sen.

Description

45-06300

X

X

X

X

1

Single Sensor

45-06301

X

X

X

X

X

2

Single Sensor w/rpm

45-06302

X

X

X

X

X

X

3

Dual Sensor w/rpm

45-06303

X

X

X

X

X

2

Single Sensor w/press

45-06304

X

X

X

X

1

Pressure Control Single

45-06305

X

X

X

X

X

2

Pressure Control, Dual

Table 1-1: PCM Cable Options

NOTE: These cable configurations are available as of 1/1/03. Contact Mid-Tech Customer Service
for other specific sensor or I/O options.
