Fieldware for The Legacy 6000
Software Version 2.11
Chapter 1 - System Introduction 1-5
Mid-Tech CAN Bus System Overview
Mid-Tech CAN Bus System Overview
The Mid-Tech CAN bus system is comprised of several components (modules). The Console, the
Power Speed Module (PSM), the Switch Sense Module (SSM), a Product Control Module (PCM),
and a Lightbar. At a minimum, four of these modules are required to have a fully functional Legacy
6000 single product control system. The lightbar is optional. To control more than one product, you
will need to add an additional PCM for each additional product you choose to control.
The Legacy 6000 Console
Dimensions: 8.0" Wide x 7.7" High x 4.5" Deep (203 x 196 x 114 mm)
Weight: 2.3 lbs. (1.0 kg)
Enclosure: High impact plastic; back lighted, tactile feed-back switches on front panel
Operator Interface: Back lighted, tactile feed-back switches on front panel
Display: 5.7" diagonal (120 x 90 mm), transflective, QVGA with CCFL back lighting. Brightness
and contrast controlled by switches on the front panel of the console.
Communication: CAN, 29 bit ID, 250K baud, Mid-Tech proprietary messages, Serial RS 232 (2),
USB: (1)
Memory: 64 Mbytes DRAM, 32 Mbytes Flash
Microprocessor: 32-bit Intel StrongARM, SA 1110 with SA 1111 companion chip. 206 MHz.
Drives: PCMCIA type II, single slot
Operating System: Microsoft Windows CE 3.0
Power Requirement: 9 to 16 volts DC
Connector: Sealed, 31 pin Deutsch
GPS Receiver Compatibility: Compatible with any differentially corrected submeter GPS (DGPS)
receiver which outputs NMEA 0183 at 2 to 10 Hz.
Alarm: Audible alarm
Other:
* Real-time clock with battery back-up
* Simple, yet versatile, RAM mounting system.
