Fieldware for the Legacy 6000
Software Version 2.11
Chapter 6 - Running Mapper 6-15
Mapper Tools
Polygon-Mark. Use to map or locate features that can be represented by a
closed shape made up of discrete points. The Map Object soft-key changes to
the Polygon-Mark soft-key. Press to mark a point along the polygon perimeter.
A prompt asks for an object name.
Polygon-Stream. Use to map or locate features that can be represented by a
closed shape made up of streaming points. The Map Object soft-key changes
to the Polygon-Stream soft-key. Press to turn streaming on and off. A prompt
asks for an object name.
Mark Boundary Polygon - Use to map the perimeter and obtain the area of a
feature by a closed shape made up of discrete points. This file is saved as a
boundary file (BND) and can be used in an ARM application as the Boundary
File.
Streamed Boundary Polygon - Use to map the perimeter and obtain the area of
a feature by a closed shape made up of streaming points. This file is saved as
a boundary file (BND) and can be used in an ARM application as the Boundary
File.
Object Description
Table 6-4: Mapping Object Description
