2-10 Chapter 2 - Getting Started
GPS Receiver Setup
Fieldware for the Legacy 6000
Software Version 2.11
GPS Receiver Setup
GPS Receiver setup defines your DGPS accuracy and how the GPS receiver communicates with
the Legacy 6000 console. GPS Receiver setup parameters are listed in Table 2-4.
Figure 2-12: The GPS Receiver Setup Menu Page
Setting Description
Use GPS Defines whether the Legacy 6000 system is using GPS. If using GPS this setting must be set to
Yes.
Accuracy Defines the accuracy of the DGPS receiver. Choices are RTK and Sub-meter.
Com Port Defines the com port that your GPS receiver is connected to.
Baud Rate Defines the selected com port baud rate.
Data Bits Defines the selected com port data bit setting.
Stop Bits Defines the selected com port stop bit setting.
Parity Defines the selected com port parity.
Table 2-4: The GPS Receiver Setup Settings
