Fieldware for the Legacy 6000
Software Version 2.11
Chapter 6 - Running Mapper 6-13
Mapper Introduction
Information Page
There is one information page which displays the current Latitude and longitude vehicle position,
Antenna Height, GPS speed, Course in degrees (North 0
o
), and file size.
Information Page SoftKeys and Description
Figure 6-11: Real-Time Information Page
Soft-key Description
The Exit soft-key. When pressed Fieldware ARM exits out of the real-time pro-
cess and returns to the Main Menu page.
The Next Page soft-key. Pressing this soft-key switches between the map page
and the rates page.
The CAN Process soft-key. When pressed this soft-key launches the CAN Pro-
cess diagnostic. This can be used to trouble shoot the CAN modules when run-
ning in real-time.
The Stop Alarm soft-key. Press this to mute an alarm.
Allows the GPS coordinates to be viewed as Latitude / Longitude or UTM
(North / East)
