A-2
Appendix A - PCM Favorites Settings
Fieldware for The Legacy 6000
Software Version 2.11
GRANSERVO-B GRANPWM-A
Favorite: GRANSERVO-A Favorite: GRANPWM-A
Application Granular Application Granular
Application name MAIN_BIN Application name MAIN_BIN
Configuration Standard Configuration Split Drive
PCM link None PCM link None
Drive Type Servo Drive Type PWM
Gain 3 Gain 1
Start Up Drive 20% Frequency 120Hz%
Master Switch Close Min.Duty Cycle 23%
Implement Status Close Max. Duty Cycle 77%
Valve Delay 1.00s Ramp Time 4 s
Valve Location In-Line Dither 5%
Master Switch Close
Implement Status Close
Valve Delay 1.00 s
Units lb/ac Units lb/ac
Control Basis Area Control Basis Area
Primary Sensor Granular Primary Sensor Granular
Input A Input A
Sensor Name CONVEYOR_SENSOR Sensor Name CONVEYOR_SENSOR
Calibration # 368.2 pul/ft3 Calibration # 717.5 pul/ft3
Cal# Basis NONE Cal# Basis NONE
Secondary Sensor None Secondary Sensor Granular
Input B
Monitor 1 None Sensor Name CONVEYOR_SENSOR
Monitor 2 None Calibration # 750.0 pul/ft3
Monitor 3 None Dual Warning % 10%
Montior 4 None Dual Warning Delay 10 s
Monitor 1 Low Bin
Input C
Sensor Name LOW_BIN_LEFT
Alarm Status High
Alarm Delay 5 s
Monitor 2 Low Bin
Input D
Sensor Name LOW_BIN_RIGHT
Alarm Status High
Alarm Delay 5 s
Monitor 3
Monitor 4
