Fieldware for the Legacy 6000
Software Version 2.11
Chapter 2 - Getting Started 2-7
System Setup
System Setup
The Fieldware System Setup allows the configuring of the Legacy 6000 to best suit job needs. To
access the System Setup launcher press the top left button in the Main Launcher page see the left
image in (Figure 2-9), the help text should say Configure System Settings. This brings up the Sys-
tem Setup Launcher page right image (Figure 2-9). The table below lists the current system com-
ponents that can be configured. Each component is covered in more detail in sections below.
Figure 2-9: System Setup Page
Setup Description
Console Defines system environment variables such as units, language, date, and time.
Lightbar Defines Swath lightbar settings and lightbar messages.
GPS Receiver Allows you to configure your GPS receiver from the Legacy 6000 console.
PCM Configures each Product Control Module that is connected to the Legacy 6000 system.
Implement Defines the vehicle’s implement, including implement width, number of swaths and sections.
Table 2-1: Current System Setup Components
