Fieldware for the Legacy 6000
Software Version 2.11
Chapter 2 - Getting Started 2-37
Product Control Module (PCM) Setup
Finishing the PCM Setup
The final page in the PCM setup process is the Finish page (Figure 2-35). From the Finish page,
select the Review all settings button to confirm setup is accurate with the machines application
(Figure 2-36). Next from the Finish Page, save the PCM setup to a file for use later (See “Saving
the PCM Setup to a File” on page 2-39.)
PCM setting can be directly applied to the PCM without saving by selecting the Send Settings to
PCM button (Figure 2-35). The PCM will use the changes made during application. If a new appli-
cation is needed and the PCM favorite or settings need to be changed all settings previous will be
lost. Saving the PCM favorites take very little time and can save much time in the future.
Figure 2-35: The PCM Setup Finish Page
Figure 2-36: The PCM Setup Summary Page
Review Settings
Button Send Settings to
PCM
Save Settings
to a File
