Chapter 2 Operations
88
2.6.2 Editing the Position Data
Position data is created using PC Software for X-SEL. Target position, speed, acceleration,
deceleration, and position complete band can be set for each axis.
Select Controller, Ex Motion Control Board (X), and then Position (P) from the menu.
Figure 2.6.3 Menu (Extension Motion Control Board Axis Position Data)
The Position data edit (Extension Motion Control Board) window appears.
Figure 2.6.4 Position data edit (Extension Motion Control Board) Window
