Chapter 4 Parameters
138
No. Parameter name Unit Input range
Default value
(reference)
Reference section
553 Extension motion control board axis 6
control input port head No.
-
XSEL-P/Q: 0~299
XSEL-R/S: 0~3999
0 4.2 [4]
554 Extension motion control board axis 6
control output port head No.
-
XSEL-P/Q: 0~599
XSEL-R/S: 0~6999
0 4.2 [4]
555 Extension motion control board axis 7
control attribute
- 0H~FFFFFFFFH 00000000H 4.2 [4]
556 Extension motion control board axis 7
control input port head No.
XSEL-P/Q: 0~299
XSEL-R/S: 0~3999
0 4.2 [4]
557 Extension motion control board axis 7
control output port head No.
XSEL-P/Q: 0~599
XSEL-R/S: 0~6999
0 4.2 [4]
558 Extension motion control board axis 8
control attribute
0H~FFFFFFFFH 00000000H 4.2 [4]
559 Extension motion control board axis 8
control input port head No.
XSEL-P/Q: 0~299
XSEL-R/S: 0~3999
0 4.2 [4]
560 Extension motion control board axis 8
control output port head No.
XSEL-P/Q: 0~599
XSEL-R/S: 0~6999
0 4.2 [4]
561 Extension motion control board axis 9
control attribute
0H~FFFFFFFFH 00000000H 4.2 [4]
562 Extension motion control board axis 9
control input port head No.
XSEL-P/Q: 0~299
XSEL-R/S: 0~3999
0 4.2 [4]
563 Extension motion control board axis 9
control output port head No.
XSEL-P/Q: 0~599
XSEL-R/S: 0~6999
0 4.2 [4]
564 Extension motion control board axis 10
control attribute
0H~FFFFFFFFH 00000000H 4.2 [4]
565 Extension motion control board axis 10
control input port head No.
XSEL-P/Q: 0~299
XSEL-R/S: 0~3999
0 4.2 [4]
566 Extension motion control board axis 10
control output port head No.
XSEL-P/Q: 0~599
XSEL-R/S: 0~6999
0 4.2 [4]
567 Extension motion control board axis 11
control attribute
0H~FFFFFFFFH 00000000H 4.2 [4]
568 Extension motion control board axis 11
control input port head No.
XSEL-P/Q: 0~299
XSEL-R/S: 0~3999
0 4.2 [4]
569 Extension motion control board axis 11
control output port head No.
XSEL-P/Q: 0~599
XSEL-R/S: 0~6999
0 4.2 [4]
570 Extension motion control board axis 12
control attribute
0H~FFFFFFFFH 00000000H 4.2 [4]
571 Extension motion control board axis 12
control input port head No.
XSEL-P/Q: 0~299
XSEL-R/S: 0~3999
0 4.2 [4]
572 Extension motion control board axis 12
control output port head No.
XSEL-P/Q: 0~599
XSEL-R/S: 0~6999
0 4.2 [4]
573 Extension motion control board axis 13
control attribute
0H~FFFFFFFFH 00000000H 4.2 [4]
574 Extension motion control board axis 13
control input port head No.
XSEL-P/Q: 0~299
XSEL-R/S: 0~3999
0 4.2 [4]
575 Extension motion control board axis 13
control output port head No.
XSEL-P/Q: 0~599
XSEL-R/S: 0~6999
0 4.2 [4]
576 Extension motion control board axis 14
control attribute
0H~FFFFFFFFH 00000000H 4.2 [4]
577 Extension motion control board axis 14
control input port head No.
XSEL-P/Q: 0~299
XSEL-R/S: 0~3999
0 4.2 [4]
578 Extension motion control board axis 14
control output port head No.
XSEL-P/Q: 0~599
XSEL-R/S: 0~6999
0 4.2 [4]
579 Extension motion control board axis 15
control attribute
0H~FFFFFFFFH 00000000H 4.2 [4]
580 Extension motion control board axis 15
control input port head No.
XSEL-P/Q: 0~299
XSEL-R/S: 0~3999
0 4.2 [4]
581 Extension motion control board axis 15
control output port head No.
XSEL-P/Q: 0~599
XSEL-R/S: 0~6999
0 4.2 [4]
